5-channel pro audio line level mono mixer in a micro form factor.
Each channel features a tilt EQ, selectable pre- or post-fader Aux and lots of gain. All inputs are High-Z, which works perfectly with all type of guitar, piezo or line signal. The Aux output is fed back to the 5th channel, awakening the monster in it by giving it even more gain, compression and distortion, ultimately leading to self-oscillation.
The μMixa provides a headphone output and can be powered by USB-C or 4xAAA batteries.
Technical Specifications:
- 5x HIGH-Z inputs, overvoltage-protected
- Each channel features a 6dB Tilt EQ at ~1kHz
- Pre-/post-fader Aux switch per channel
- Gain: 18dB input / 18dB aux / 12dB output
- Aux is routed back to (x) and can be used as a gain multiplier
- (x) becomes a 5th channel by inserting a plug
- 6.35mm TRS main output jack, mono with signal on tip and ring
- Output: 10dBu (max.)
- Adjustable headphone output via 3.5mm TRS jack
- Super linear frequency response: 20Hz–20kHz (< -0.1 dB)
- Dimensions: 106 x 74 x 44mm
- Weight: 155g
- Power supply: USB-C or 4x AAA batteries
- Current consumption: 30mA (max.)
- Battery life: more than 24 hours
Status: v1.0, Preorder possible
169,00€ fully assembled
Order
More info, docs and demo coming soon.
